Home / Regular Issue / JTAS Vol. 44 (2) May. 2021 / JTAS-2205-2021


In silico Characterization of the Structure of Genes and Proteins related to β-carotene Degradation in Musa acuminata ‘DH-Pahang’ and Musa balbisiana ‘Pisang Klutuk Wulung’

Fenny Martha Dwivany, Nisrina Sukriandi, Karlia Meitha and Tatas H. P. Brotosudarmo

Pertanika Journal of Tropical Agricultural Science, Volume 44, Issue 2, May 2021

DOI: https://doi.org/10.47836/pjtas.44.2.10

Keywords: A genome, B genome, β-carotene, CCD, D27

Published on: 28 May 2021

β-carotene is an important nutritious content in banana. However, its lifetime depends on the enzymes controlling its conversion into strigolactone. To understand the involved enzymes’ activity, which are β-carotene isomerase (D27), carotenoid cleavage dioxygenase 7 (CCD7), and CCD8, would be the key to manipulate the rate of β-carotene degradation. In this research, we characterized the structure of genes and proteins of the D27, CCD7, and CCD8 from Musa acuminata ‘DH-Pahang’ and Musa balbisiana ‘Pisang Klutuk Wulung’ (PKW). We aligned the corresponding sequence of genes from both species to determine similarity and intron/exon positions. We also identified domains and motifs in the sequences of putative proteins of D27, CCD7, and CCD8. We found that D27, CCD7, and CCD8 genes in DH-Pahang and PKW comprise of various nucleotide sequence length, putative proteins, and numbers and length of exons and introns. However, the putative proteins possess the same domains: DUF4033 (domain of unknown function) in D27 and RPE65 (retinal pigment epithelium) in CCD7 and CCD8. Phylogenetic trees showed that D27, CCD7, and CCD8 proteins from DH-Pahang and PKW are conserved and clustered in the same clades with the same proteins of monocot plants. Hence, the results could be useful for future research in optimizing β-carotene content in banana.

  • Ahrazem, O., Gómez-Gómez, L., Rodrigo, M. J., Avalos, J., & Limón, M. C. (2016). Carotenoid cleavage oxygenases from microbes and photosynthetic organisms: Features and functions. International Journal of Molecular Sciences, 17(11), 1781. https://doi.org/10.3390/ijms17111781

  • Alder, A., Jamil, M., Marzorati, M., Bruno, M., Vermathen, M., Bigler, P., Ghisla, S., Bouwmeester, H., Beyer, P., & Al-Babili, S. (2012). The path from β-carotene to carlactone, a strigolactone-like plant hormone. Science, 335(6074), 1348–1351. https://doi.org/10.1126/science.1218094

  • Altschul, S. F., Gish, W., Miller, W., Myers, E. W., & Lipman, D. J. (1990). Basic local alignment search tool. Journal of Molecular Biology, 215(3), 403–410. https://doi.org/10.1016/S0022-2836(05)80360-2

  • Bailey, T. L., & Elkan, C. (1994). Fitting a mixture model by expectation maximization to discover motifs in biopolymers. Proceedings International Conference on Intelligent Systems for Molecular Biology, 2, 28–36.

  • Batra, R., Agarwal, P., Tyagi, S., Saini, D. K., Kumar, V., Kumar, A., Kumar, S., Balyan, H. S., Pandey, R., & Gupta, P. K. (2019). A study of CCD8 genes/proteins in seven monocots and eight dicots. PLOS One, 14(3), 1–21. https://doi.org/10.1371/journal.pone.0213531

  • Buah, S. (2015). Regulation of carotenoid biosynthesis in banana fruit (Doctoral thesis, Queensland University of Technology, Australia). Queensland University of Technology ePrints. https://eprints.qut.edu.au/82719/

  • Calberto, G., Staver, G. C., & Siles, P. (2015). An assessment of global banana production and suitability under climate change scenarios. In A. Elbehri (Ed.), Climate change and food systems: Global assessments and implications for food security and trade (pp. 266-291). Food Agriculture Organization of the United Nations (FAO).

  • Clark, K., Karsch-Mizrachi, I., Lipman, D. J., Ostell, J., & Sayers, E. W. (2016). GenBank. Nucleic Acids Research, 44(D1), D67-D72. https://doi.org/10.1093/nar/gkv1276

  • D’Hont, A., Denoeud, F., Aury, J.-M., Baurens, F.-C., Carreel, F., Garsmeur, O., Noel, B., Bocs, S., Droc, G., Rouard, M., Da Silva, C., Jabbari, K., Cardi, C., Poulain, J., Souquet, M., Labadie, K., Jourda, C., Lengellé, J., Rodier-Goud, M., … Wincker, P. (2012). The banana (Musa acuminata) genome and the evolution of monocotyledonous plants. Nature, 488(7410), 213–217. https://doi.org/10.1038/nature11241

  • Davey, M. W., Gudimella, R., Harikrishna, J. A., Sin, L. W., Khalid, N., & Keulemans, J. (2013). “A draft Musa balbisiana genome sequence for molecular genetics in polyploid, inter- and intra-specific Musa hybrids”. BMC Genomics, 14(1), 683. https://doi.org/10.1186/1471-2164-14-683

  • Englberger, L., Wills, R. B. H., Blades, B., Dufficy, L., Daniells, J. W., & Coyne, T. (2006). Carotenoid content and flesh color of selected banana cultivars growing in Australia. Food and Nutrition Bulletin, 27(4), 281–291. https://doi.org/10.1177/156482650602700401

  • Florea, L., Hartzell, G., Zhang, Z., Rubin, G. M., & Miller, W. (1998). A computer program for aligning a cDNA sequence with a genomic DNA sequence. Genome Research, 8(9), 967–974. https://doi.org/10.1101/gr.8.9.967

  • Hall, T. A. (1999). BioEdit: A user-friendly biological sequence alignment editor and analysis program for Windows 95/98/NT. Nucleic Acids Symposium Series, 41, 95–98.

  • Häuser, R., Pech, M., Kijek, J., Yamamoto, H., Titz, B., Naeve, F., Tovchigrechko, A., Yamamoto, K., Szaflarski, W., Takeuchi, N., Stellberger, T., Diefenbacher, M. E., Nierhaus, K. H., & Uetz, P. (2012). RsfA (YbeB) proteins are conserved ribosomal silencing factors. PLOS Genetics, 8(7), e1002815. https://doi.org/10.1371/journal.pgen.1002815

  • Huelsenbeck, J. P., & Ronquist, F. (2001). MRBAYES: Bayesian inference of phylogenetic trees. Bioinformatics (Oxford, England), 17(8), 754–755. https://doi.org/10.1093/bioinformatics/17.8.754

  • Jones, P., Binns, D., Chang, H.-Y., Fraser, M., Li, W., McAnulla, C., McWilliam, H., Maslen, J., Mitchell, A., Nuka, G., Pesseat, S., Quinn, A. F., Sangrador-Vegas, A., Scheremetjew, M., Yong, S.-Y., Lopez, R., & Hunter, S. (2014). InterProScan 5: Genome-scale protein function classification. Bioinformatics, 30(9), 1236–1240. https://doi.org/10.1093/bioinformatics/btu031

  • Madeira, F., Park, Y. M., Lee, J., Buso, N., Gur, T., Madhusoodanan, N., Basutkar, P., Tivey, A. R. N., Potter, S. C., Finn, R. D., & Lopez, R. (2019). The EMBL-EBI search and sequence analysis tools APIs in 2019. Nucleic Acids Research, 47(W1), W636–W641. https://doi.org/10.1093/nar/gkz268

  • Marchler-Bauer, A., Bo, Y., Han, L., He, J., Lanczycki, C. J., Lu, S., Chitsaz, F., Derbyshire, M. K., Geer, R. C., Gonzales, N. R., Gwadz, M., Hurwitz, D. I., Lu, F., Marchler, G. H., Song, J. S., Thanki, N., Wang, Z., Yamashita, R. A., Zhang, D., … Bryant, S. H. (2017). CDD/SPARCLE: Functional classification of proteins via subfamily domain architectures. Nucleic Acids Research, 45(D1), D200–D203. https://doi.org/10.1093/nar/gkw1129

  • Mathew, D., & Muhammed, T. A. (2015). Nutritional studies on lesser known wild edible bananas from Western Ghats, India. Global Journal of Research on Medical Plants and Indigenous Medicine, 3(4), 127–133.

  • Mishra, S., Upadhyay, S., & Shukla, R. K. (2017). The role of strigolactones and their potential cross-talk under hostile ecological conditions in plants. Frontiers in Physiology, 7, 691. https://doi.org/10.3389/fphys.2016.00691

  • Notredame, C., Higgins, D. G., & Heringa, J. (2000). T-coffee: A novel method for fast and accurate multiple sequence alignment. Journal of Molecular Biology, 302(1), 205–217. https://doi.org/10.1006/jmbi.2000.4042

  • Page, R. D. (1996). Tree View: An application to display phylogenetic trees on personal computers. Bioinformatics, 12(4), 357–358. https://doi.org/10.1093/bioinformatics/12.4.357

  • Ronquist, F., & Huelsenbeck, J. P. (2003). MrBayes 3: Bayesian phylogenetic inference under mixed models. Bioinformatics, 19(12), 1572–1574. https://doi.org/10.1093/bioinformatics/btg180

  • Solovyev, V., Kosarev, P., Seledsov, I., & Vorobyev, D. (2006). Automatic annotation of eukaryotic genes, pseudogenes and promoters. Genome Biology, 7(Suppl 1), S10. https://doi.org/10.1186/gb-2006-7-s1-s10

  • Wang, Y., Ding, G., Gu, T., Ding, J., & Li, Y. (2017). Bioinformatic and expression analyses on carotenoid dioxygenase genes in fruit development and abiotic stress responses in Fragaria vesca. Molecular Genetics and Genomics, 292(4), 895–907. https://doi.org/10.1007/s00438-017-1321-5

  • Waters, M. T., Brewer, P. B., Bussell, J. D., Smith, S. M., & Beveridge, C. A. (2012). The Arabidopsis ortholog of rice DWARF27 acts upstream of MAX1 in the control of plant development by strigolactones. Plant Physiology, 159(3), 1073–1085. https://doi.org/10.1104/pp.112.196253
